Promo PS65W

A floor-standing wall-propped indoor portrait retail display

Featuring

  • Impact Resistant Glass
  • ADA Compliant and People Friendly

Promo PS65 Wall-mounted Display

Promo displays are commercial grade digital display systems, with an integrated 1000nit LCD display, this wall-mounted single digital face unit incorporates our telemetry suite reporting important attributes of the system to a central Network Operating Center [NOC]

The system is modular in its architecture & construction, with full maintenance access from the front via the top hinged fascia. A range of playback and network devices may be selected according to required specification and region, interactive touch & camera options are available.

Exploded System Assembly
Exploded System Assembly

Modular Construction

  • Free-standing indoor portrait digital display system, for permanent installation to a concrete floor. Other mounting configurations may be derived upon request.
  • 65” diagonal portrait UHD LCD display panel with long-life LED backlighting.
  • Direct-air cooled thermal management 0 < 40 Celsius.
  • Modular construction and assembly, for ease of maintenance and upgrade in the field.
  • Secure maintenance access from the rear.
  • Rugged steel and aluminium fabricated housing with polyester powder coated finish in black.
  • Full glass fascia with AR coatings and black image surround.
  • Integrated fascia branding and logo.
  • Optional supermarket trolley/cart bumper rail baseplate.
  • Sensor driven integrated telemetry, for network reporting, device management and data analytics.
  • Content player, cellular router & antenna integrated – range of options available.
  • Camera and interactive touch fascia options.

PRA-007-005-003GA

General Arrangement Drawing

[2] A4 Sheets

Elevations with Overall Dimensions & Exploded View

Download the Document

PRA-007-005-003 Outline Specification

Download the Document
PRA-007-005-003GA
PRA-007-005-003 Outline Specification

Do you have a project?

Talk to the experts

System Specifications

Model
Promo PS65W
Market
Retail
Resolution
3840x2160
Environment
Indoor
Environmental Management
Direct Air Cooled, Sensor Driven Self-Governing, Telemetry
Display Size
65"
Platform
Promo
Brightness
1000 nits
Orientation
Portrait
Faces
Single Digital
Certification
CB, C-Tick
